GiCor has been creating outdoor living spaces for our clients using a wide range of product solutions. Corradi USA is an Italian based company that provides a variety of systems proven for the North American market. By transforming outdoor areas into elegant living spaces through their motorized retractable shade systems such as “Pergotenda” they have become renowned for their product line.
Pergotenda
These are made to measure systems for the protection from sun, rain, and in some instances even snow (when heated) which can be free standing, installed against the building structure or, if suitable, on pre-existing structures. The systems are typically made with aluminum or wood structures depending on the size & nature of the project requirements. Pitched versions have guaranteed wind resistance from grade 6 to 8 on the Beaufort scale, while flat versions have grade 6 resistance (above class 3 – UNI EN 13561). The folding canvas or Vinyl coated fabrics are available in a wide range of options to suit any design. This fabric is supported by intermediate supporting tubes and terminal bars set parallel to one another that move by sliding on side tracks / carriers with asymmetrical wheels. Faux ceilings are also available as a second layer with the Impact system to create a more decorative appearance from below.
“Millenium” can be made pitched or flat and up to 512″ wide x 232″ in length
“Irridium” can also be made pitched or flat and up to 512″ wide x 256″ in length
“Impact” & B-Space can be made pitched or flat and up to 512″ wide x 354″ in length
“Kubo” is a flat system with maximum dimensions of 413″ wide x 236″ long
“Exyl” is the most economical Pergotenda and is made as a flat retractable roof up to 413″ wide x 236″ long
“Pergotenda 45″ is our most traditional wood design, available pitched or flat up to 512″ wide x 232” long
“Pergotenda 60″ is our most traditional wood design, available pitched or flat up to 512″ wide x 307” long
“Pergotenda 100″ is our most traditional wood design, available pitched or flat up to 413″ wide x 276” long
“Arko” is a unique “awning like” modern wood structure retractable cover that is wall mounted and can be made up to 472″ wide x 157″ projection.
Exterior Screens
Corradi’s exterior shading systems can be a very effective way of keeping the elements out and extending the season to enjoy your outdoor gazebos & patios. Exterior shading using guide wires (Vista) can be used to reduce UV & heat gain as well as to eliminate glare. “Stratus” is a zipper screen made in two models; “Summit” & “Harbour” which can be used to create a “bug free” zone as well as to minimize wind in areas that are prone to high wind load. Available in manual & motorized systems, they can be designed for roof mounted applications, wall & soffit mounted as well as recessed into the building structure with some additional planning. Fabrics are most often screen style base cloths with an opacity between 0 to 60% open depending on the desired outcome.
“Summit” is available with a round or squared cassette up to 18 feet wide x 16 feet long
“Harbour” is available with a curved radius cassette up to 23 feet wide x 16 feet long
Horizon
The Horizon is a unique answer to controlling the sun’s harsh UV rays with the adaptability to be installed on any flat or even surface at any angle making it perfect for pergola and skylight applications. This system is made for interior & exterior skylight shading and can be mounted to any suitable existing structure. It is designed to cover large areas with its cord tensioned side guides and a spring loaded bottom rail with no need for center cord supports. It can be used for larger bottom up applications and is capable of treating spaces of up to 195 square feet. Multiple systems can be adjoined for even greater coverage. Fabric options include solar screening materials & Acrylic fabrics. Maximum widths up to 15 feet with a maximum projection of 15 feet. Base model frame is white gloss however custom powder coating options are available. Control options include; sun, rain & wind sensors, remote controls, wall switches, smart phones or home automation systems.
Velombra
The new “Defense” system is a retractable “Sail” styled awning available up to 14 square meters. There are three possible anchorage options: direct anchoring to the ground, anchored to an optional lock plate which would be inserted into the concrete pouring, or with an optional weighted cross-base complete with AISI 316 stainless steel base cover.
These shades can be rotated through 90° & the canvas can be rolled up in a few seconds manually or by means of a radio controlled motor reducer. Fabrics are typically Dacron with a fiberglass reinforcement.
Alba
Corradi’s NEW Alba louvered roof pergolas are aluminum outdoor structures equipped with adjustable blades that can be rotated up to 150 degrees. Maximum dimensions (coupled) up to 236″ wide x 238″ in length. The rotation of the blades create a comfortable environment for all seasons as blade direction can shield, divert or eliminate direct glare altogether. Rain, no problem,,,,, rotate the louvers to the closed position and water will drain thru the patented gutters to the outsides and down the aluminum vertical columns. Control options include; sun, rain & wind sensors, remote controls, wall switches, smart phones or home automation systems. Add LED lighting (fully dimmable) to create that perfect atmosphere.
Water Resistance: 830 gallons/hr
Maximum payload: 22.53 pounds/sq ft
Wind Resistance: up to 75 miles per hour with louvers closed
Awnings
Get ready to join the Aesthetic Revolution! Modern design, cutting edge performance and its marked aluminum profile make Corradi awnings perfectly in line with contemporary urban architecture. Awnings are typically installed on the exterior of a building & can greatly enhance both the appearance and functionality of any residential or commercial building. Fabrics include blackout, screen and decorative cloths. Control options include manual cranks or for larger systems, motorized is always the best option.
“Shan” is a state of the art awning with a modern squared cassette that can be made up to 23 feet with a projection up to 162″, pitches up to 65 degrees
“Svet” is an open roll awning with contemporary design that can also be made up to 23 feet with a projection up to 162″, pitches up to 65 degrees
“Ilios Wing” is a retractable awning with a drop down arm to secure for areas whee high wind is present. This can be made up to 17 feet wide x 63″ project (at a 90 degree angle)
GENERAL NOTES:
Most systems are set in motion by radio-controlled motors which can be operated using a range of control systems such as remotes, wall switches, sun sensors as well as smart phone and home automation systems. Wind & rain sensors can also be added to retract the shades in wet or high wind conditions at a moment’s notice.
Remember, mounting, electrical & sometimes engineering requirements vary from application to application so call us as early on in the project as possible to ensure that your installation turns out just the way you had envisioned.
